Overview
The Kingsman HBZDV 47" is the ultimate in Zero Clearance Direct Vent Fireplaces for new home construction or renovation, and your best choice for installation anywhere throughout your home.
Features:
- Millivolt or IPI valve system allows operation during a power failure with Hi/low heat and flame adjustment
- Dual burner with Realistic Flame Pattern
- A flame sensor that constantly monitors the pilot flame
- Safety Screen Barrier
- Wall Switch
- Tempered Glass
- Listed in USA/Canada as a Vented Gas Fireplace
Specifications:
| Model | HBZDV4736N/NE | HBZDV4736LP/LPE |
| Fuel | Natural Gas | Propane |
| Flue | Top | Top |
| Gas Control | Millivolt/IPI | Millivolt/IPI |
| Max BTU | 40,000 | 36,000 |
| Min BTU | 27,000 | 30,000 |
| FE (p.4.1-02)% | 60.39% / 61.88% | 53.79% / 54.9% |
| Venting | 4/7" | 4/7" Flex or 4/6 5/8" Hard Pipe |
| Viewing Area | 39 1/2" W x 26 3/8" H | 39 1/2" W x 26 3/8" H |
| Actual Width (CVCK) | 48 1/16" | 48 1/16" |
| Actual Height (CVCK) | 49" | 49" |
| Actual Depth (CVCK) | 21 15/16" | 21 15/16" |
| Actual Width (Louvers) | 47 1/16" | 47 1/16" |
| Actual Height (Louvers) | 43 1/16" | 43 1/16" |
| Actual Depth (Louvers) | 19 7/16" | 19 7/16" |
