Osburn INSPIRE 2000 Wood Stove - OB02042 TAX CREDIT QUALIFIED

Now: $2,949.00

| Model #:
OB02042

"*" INDICATES REQUIRED FIELDS

Clear All

Please select all the required options

Osburn INSPIRE 2000 Wood Stove - OB02042 TAX CREDIT QUALIFIED

In Stock

Now: $2,949.00

Tax Credit Form         Manual           Spec Sheet



Are you interested in getting off the beaten path? The Inspire offers a style that will surely withstand variable trends with these pure lines of balanced proportions, allowing the brand  Osburn to easily compare to European-style products. This more contemporary look is available on steel base, soapstone or even a minimalist base for those who prefer to place the unit directly on a non-combustible podium. Equipped with a 2.3 cubic feet firebox and an outside air intake, this unit will meet the requirements of domestic energy standards, not to mention that a mobile home installation is permitted.

 The Inspire meets EPA requirements with emissions as 2.3 g/h and complies with the most stringent North American requirements. A guarantee of quality, reliability and durability, once again Osburn clearly demonstrates its firm commitment to the environment to the delight of wood heating fans.



Optional Accessories:



Features:

Combustion technology Non-catalytic
High-efficiency certified appliance Yes, EPA 2020 approved
Maximum log length 20"
Log positioning Loading over width
Chimney diameter 6"
Flue outlet diameter 6"
Type of chimney CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height (feet) 12'
Baffle type C-Cast or equivalent
Approved for an alcove installation Yes
Approved for a mobile home installation Yes, with fresh air intake
Shipping Weight 537 lb (244 kg)
Door type Single, glass with steel frame
Glass type Ceramic glass
Glass surface – dimensions (Width X Height) 20 1/4" X 9 1/2"
Glass air-wash system Yes
Overall dimension (Height) 35 5/8"
Overall dimension (Width) 27 7/8"
Overall dimension (Depth) 24 1/4"
Door opening – dimension (Height) 8 3/8"
Door opening - dimension (Width) 20"
Firebox – dimension (Height) 11 3/4"
Firebox – dimension (Width) 21"
Firebox – dimension (Depth) 16 3/4"
Firebox lined with refractory bricks for better heat distribution Yes
Stainless-steel secondary-air system improving gas combustion Yes
Model Pedestal
Steel thickness – body 3/16"
Steel thickness – top 5/16"
Easy-to-access ash drawer Yes
USA standard (emissions) EPA Method 28
Canadian Standard (emissions) CSA B415.1-10
USA standard (safety) UL 1482, UL 737
Canadian standard (safety) ULC S627
Tested and listed as per applicable standards By an accredited laboratory (CAN/USA)
Warranty Limited lifetime


Appliance Performance:
Fuel type : Dry cordwood (16" recommended)
Recommended heating area-ft² : () 500 - 2,100
Overall firebox volume-ft³ : 2.4
EPA loading volume-ft³ : 1.95
Maximum burn time : () 8 h
Maximum heat output-dry cordwood : (2) 75,000 BTU/h (22.0 kW)
Overall heat output rate < : (2) (3) 14,200 BTU/h (4.16 kW) to 44,500 BTU/h (13.04 kW)
Average overall efficiency (dry cordwood) : (3) 72 % (HHV) (4) 77 % (LHV) (5)
Optimum overall efficiency : (6) (7) 79 %
Optimum heat transfer efficiency : (8) 76 %
Average particulate emissions rate : (9) 2.3 g/h
Average CO : (10) 69 g/h
